特性
|
单位
|
|
|
|
|
|
|
1
|
型号Model
|
|
S10
|
S12
|
S15
|
S20
|
S100
|
|
2
|
类型Type
|
|
窄腿
|
窄腿
|
窄腿
|
|
平衡重式
|
|
3
|
门架类型Mast type
|
|
两级标准
|
两级标准
|
两级全自由
|
|
两级标准/两级全自由
|
|
4
|
额定载荷Load capacity
|
kg
|
1000
|
1200
|
1500
|
2000
|
1000
|
|
5
|
载荷中心距Load center
|
mm
|
600
|
600
|
600
|
600
|
500
|
|
6
|
操作类型Operating type
|
|
步行式/乘驾式Walkie/Stand On
|
|
7
|
轴距Wheel base
|
mm
|
|
|
|
|
|
|
|
车轮Wheels
|
|
|
|
|
|
|
|
8
|
轮子类型（前/后）Wheels type
|
|
|
|
PU
|
|
|
|
9
|
轮子数量Wheels quantity
|
|
驱动轮1/平衡轮2/承重轮4
|
驱动轮1/承重轮2
|
|
|
尺寸Demension
|
|
|
|
|
|
|
|
10
|
标准门架起升高度Standard lift height
|
mm
|
|
|
3000
|
|
|
|
11
|
货叉zui低高度Lowered fork height
|
mm
|
|
|
85
|
|
55
|
|
12
|
货叉规格尺寸Fork size
|
mm
|
|
1150/185/55
|
|
1070/100/40
|
|
13
|
整车全长，踏板收起/放下Overall length
|
mm
|
1993/2413
|
2050/2470
|
2502/3012
|
|
14
|
车体宽度Overall width
|
mm
|
|
812
|
|
856
|
1015
|
|
15
|
门架zui高高度Max extend height
|
mm
|
|
3500
|
|
|
4000/3600
|
|
16
|
门架静态高度Mast lowered height
|
mm
|
1980
|
|
2080
|
|
2030/2080
|
|
17
|
zui小转弯半径Min Turning radius
|
mm
|
1525/1935
|
1580/1990
|
1352/1852
|
|
18
|
zui小离地间隙Min ground clearance
|
mm
|
|
30
|
|
|
80
|
|
|
性能Performance
|
|
|
|
|
|
|
|
19
|
zui大行驶速度，满载/空载
|
km/h
|
|
|
|
|
|
|
|
Travel speed laden/unladen
|
|
|
|
5/5
|
|
|
|
20
|
zui大起升速度，满载/空载
|
mm/s
|
|
|
130/230
|
|
|
|
|
Lift speed laden/unladen
|
|
|
|
|
|
|
|
21
|
zui大下降速度，满载/空载
|
mm/s
|
|
|
130/230
|
|
|
|
|
Travel speed laden/unladen
|
|
|
|
|
|
|
|
22
|
爬坡度，满载/空载
|
%
|
|
|
5/5
|
|
|
|
|
Gradeability laden/unladen
|
|
|
|
|
|
|
|
|
电气配置Electeical configuration
|
|
|
|
|
|
|
|
23
|
电机Motor
|
Kw
|
驱动电机 AC1.5，起升电机DC3，转向电机DC0.15
|
|
24
|
蓄电池电压Battery voltage
|
V
|
|
|
24
|
|
|
|
25
|
蓄电池容量Battery capacity
|
Ah
|
210
|
|
|
280
|
270
|
|
26
|
制动 Brake
|
|
|
|
电磁/再生
|
|
|
27
|
控制器型号Controller
|
|
|
|
CURTIS 1230
|
|
|
|
重量Weight
|
|
|
|
|
|
|
|
28
|
蓄电池重量Battery weight
|
kg
|
190
|
|
235
|
|
245
|
|
29
|
自重（包含蓄电池）
|
kg
|
1110
|
1204
|
1330
|
1578
|
1800/1930
|
|
|
Service weight with battery
|
|
|
|
|
|
|
